제품규격

  • HOME
  • 제품규격
  • SOLID 규격

SOLID 규격


TIRE
SIZE
 RIM PATT. LOAD CAPACITY(kg) WEIGHT (kg)
DIMENSION(mm) - FORK-LIFT TRUCKS - OTHER VEHICLES(TRAILERS)
Up to 25km/h
OVERALL
DIA. 		OVERALL
WIDTH 		Load W. Steer W. Up to
6km/h		 Up to
10km/h 		Up to
25km/h
3.00-4 2.10 CBX 250 85 260 195 260 235 195 4.5
4.00-4 2.50C CBX 306 105 535 410 535 485 410 7.3
3.05-5 2.50 LUG 293 99 540 420 540 500 420 7.0
4.00-8 3.00D RIB.LUG 405 108 950 730 950 860 730 11.5
3.75P RIB.LUG 12.0
5.00-8 3.00D CBX 458 125 145 1090 1415 1285 1090 17.8
3.75P CBX 18.3
15X41/2-8 3.00D CBX 376 115 1040 800 1040 940 800 10.1
3.251 CBX 10.3
16X6-8 4.33R CBX 415 138 1270 975 1270 1150 975 15.8
18X7-8 4.33R CBX 461 157 2145 1650 2145 1945 1650 22.1
18X9-8 7.0 CBX 462 208 2300 1900 2300 2090 1900 31.6
6.00-9 4.00E CBX 530 139 1885 1450 1885 1710 1450 28.5
7 - 9 4.33R CBX 550 157 2340 1800 2340 2125 1800 31.5
5.00S CBX 32.0
21X8-9 6.00E CBX 518 184 2755 2120 2755 2505 2120 34.9
21X9-9 7.00E CBX 524 206 3235 2490 3235 2935 2490 39.0
6.50-10 5.00F CBX 574 172 2340 1800 2340 2125 1800 37.5
5.50F CBX 38.0
7.50-10 5.00F CBX 630 192 3070 2360 3070 2785 2360 55.0
5.50F CBX 55.5
23X9-10 6.50E CBX 583 204 3160 2430 3160 2875 2430 49.1
7.00-12 5.00S CBX 653 172 2920 2240 2920 2645 2240 48.6
23X9-12 6.0 CBX 583 231 2600 2000 2600 2400 2000 50.0
23X10-12 8.00G CB 589 240 3600 2770 3600 3270 2770 55.3
27X10-12 8.00G CBX 676 246 3900 3000 3900 3540 3000 78.5
23X5 3.75P CBX 622 138 1495 1150 1495 1355 1150 32
25X6 3.75P CBX 665 148 2210 1700 2210 2005 1700 41.5
7.00-15 5.5 CB.CBX 734 175 3545 2725 3545 3215 2725 61.4
7.50-15 5.5 CBX 755 197 3900 3000 3900 3540 3000 71.6
6.0 CBX 72.4
6.5 CBX 73.2
8.15-15
(28X9-15)		 7.0 CBX 696 212 3445 2650 3445 3125 2650 64.0
8.25-15 5.5 CBX 807 202 4750 3650 4750 4300 3650 87.0
6.5 CBX 88.0
250-15 7.0 CBX 716 226 4640 3570 4640 4200 3570 70.8
7.5 CBX 71.5
300-15 8.0 CBX 812 266 5735 4410 5735 5210 4410 116.0
28X12.5-15 9.75 CBX 711 310 5000 3850 5000 4545 3850 97.0
32X12.1-15 9.75 CBX 807 300 6500 5000 6500 5900 5000 132.7
6.50-16 4.5 CBX.PL 742 175 2500 2000 2600 2360 2000 59.0
5.50F CBX 60.6
7.50-16 5.5 CBX 782 195 3950 3050 3950 3600 3050 76.8
6.00GS CBX 77.9
8.00-16 5.5 CBX.PL 807 205 4180 3190 4180 3800 3190 88.4
9.00-16 5.5 PL 835 230 4430 3405 4430 4010 3405 113.0
LUG 112.0
6.5 LUG 5240 4030 5240 4745 4030 113.0
8.25-20 6.5 LUG 940 220 4800 3675 4800 4335 3675 117.0
9.00-16 6.5 PL 4430 3405 4430 4010 3405 113.0
LUG 112.0
6.5 LUG 5240 4030 5240 4745 4030 113.0
8.25-20 6.5 LUG 940 220 4800 3675 4800 4335 3675 117.0
9.00-20 6.5 LUG 1006 232 5375 4450 5375 4885 4450 152.0
7.0 LUG 154.0
8.0 LUG 156.5
10.00-20 7.50V LUG 1025 258 6000 5000 6000 5455 5000 174.5
8.00V LUG 176.5
11.00-20 8.00V CBX 1058 280 6500 5425 - - - 205.0
12.00-20 8.00V CBX 1092 297 7500 6250 - - - 233.5
10.00W CBX 238.0
12.00-24 8.00V CBX 1193 297 7980 6650 - - - 270.0
100.00W CBX 275.0
14.00-24 8.0V CBX 1313 340 11000 9175 - - - 388.0
10.00W CBX 394.0
